The axial nozzles are designed as complete cone spiral nozzle consisting of a casing and an insert. Correctly assembled, the nozzles distribute the water with a spray angel of 120°, where the water flow rate depends on the operational pressure. We recommend checking the operation conditions, as nozzle distance and height have to be chosen according to the respective plant requirements.
Features:
Features of our 2H SPN Spray Nozzles:
Low clogging and scaling tendency due to smooth surface design
Constant self-cleaning by high turbulence in the nozzle body
Easy installation onto the piping system due to BSP thread and hexagon body design
High resistance to a large range of chemicals because the nozzles are made of glass reinforced polyamide (nylon)
We offer water distribution nozzles for cooling towers, humidifiers, scrubbers, air coolers and aerators. These nozzles are made of glass fiber reinforced polyamide (nylon) and are resistant to a large range of chemicals. Their smooth surface impedes clogging and scaling. The spray angel of 120° provides an optimum water distribution above the cooling tower packing.
