Imac - Model 7580 RB 25 30 - Automatic Onion Loader

Details

• Lenght 770 cm
• Width 285 cm
• Height 310 cm
• Output Ha/8h (Potatoes) 0,60 - 1,70
• Output Ha/h (Onions) on demand
• Power requirement 55 kw
• Weight 5500 kg
• Sieving channel 75 cm
• Elevator-defoliator channel 80 cm
• Transversal channel 72 cm
• Sorting web channel 70 cm
• Scrap web channel 38 cm
• Hopper capacity 2500-3000 kg

Additional Information

• Hydraulic foot
• Drawbar for lower hitch with adjustable height
• Hydraulic equipment for harvesting in 2 phases with rubber paddlesand rotor shaft or with synthetic roller
• Fast change pick up
• Rubber shakers with manually adjustable intensity on sieving web
• Cardan shaft with clutch
• Sieving web pitch 40 mm with straight bars Ø 11 mm
• Elevator web pitch 35 mm with straight bars Ø 11 mm and rubber porters
• Wide mesh haulm web around the elevator web – Vulcanized bars with rubber fingers
• 5 rows of haulm intake combs mounted on springs with manually adjustable angle
• Haulm tearing roller placed under defoliator web
• Hydraulically driven transversal hedgehog and manually adjustable angle
• Hydraulic rotary comb with adjustable speed and retaining roller with independent hydraulic system
• Sorting table with hydraulic adjustable speed linked to tractor system
• Chute for discharging on both sides (1 on the right and 1 on the left)
• Large sorting table up to 5 persons reachable on both sides
• Acustic signal
• 4 rows of sorting rollers
• Hydraulically driven drawbar
• Hydraulically driven axle steering
• Electro-hydraulic controls
• Hydraulic system powered:
  A) Pistons, sorting table and the hopper engine linked to the tractor system
  B) Rotary comb and transversal hedgehog with an independent hydraulic system
• Loose web to fill up the hopper with adjustable position and with electric control from the selection table and the tractor
• Tyres 400/55 – 22,5

Main Optionals

• 2 speed gearbox
• 2 additional cleaning rolles at the exit of the cleaning hedgehog
• Separation kit for stones with hydraulically driven rotary brush and retaining roller (instead of rotary fingers)
• Stone hopper (with hydraulic opening)
• Additional haulm intake combs (1 row)
• Separation kit for small onions with hopper and an hydraulically driven discharging web (hydraulic extension)
• Fall breaker at the end of the hopper
• Road lights (without road traffic approval)
• Automatic centring of the sieving channel
• Automatic centring of the wheels
• Kit for carrots (including hydraulically driven grass cutting discs 1 left and 1 right)
• Digging depth control through a hydraulically level wheel
• Digging depth control through a mechanical level wheel
• Automatic hopper filling up
• Electric adjustment of the web shaker on first sieving web
• Tyre 500/45 – 22,5 (1 pcs) (instead of the standard one)
• Monitor with 2 cameras
• Parasol roof
• Supplementary haulm tearing roller (1 pcs)
• Stone hopper with hydraulically driven unloading web JP
• Hopper for small onions with high unloading JP
• Additional control box
• Braking system (oil or compressed air)
• Road traffic approval (valid only for Italy)
